$130.00
Space-conscious lowpass filter
Availability:Out of stock
BrandBefaco
Space-conscious lowpass filter and volume processor.
A combination of VCF + VCA + Mixer that lets you mix three different sound sources, and shape their tone, and levels in a breeze.
The Pony Filter is built around the SSI2144 FATKEYS™ Chip. Has the elegant sound of the classic transistor filter without the associated distortions, due to Dave Rossum’s “improved ladder” topology.
FEATURES
- 3 Channel Mixer (Out normalized to channel three for feedback)
- Temperature-compensated Q and frequency.
- Compensated Volume VS Resonance
- b2 Cuttof CV INs.
- CV 1 Selectable routing Cut-Off or Cut-Off+VCA
- Voltage controlled Q
- Two Segment Peak Meter
| Brand | Befaco |
|---|---|
| HP | 6 |
| Depth | 35mm |
| +12V | 50mA |
| -12V | 45mA |
| Additional Resources | Build Guide |
| 3D Thumbnail | /b/e/bef-pony_vcf_plate.jpg |
