Meng Qi DU-KRPLS Partial Kit - a circuit bent digital waveguide in a DIY Eurorack kit.

This is for a partial kit in the Eurorack format. It includes PCBs, panel, IC and two precision resistors. You'll need to supply all other components.

- +
Availability:In stock

Circuit-Bent Digital Waveguide™ 扰动数字波导 -  A collaboration between Detroit Underground™ and Meng Qi.

DU-KRPLS explores and exploits errors in code, achieving non-linearity in control and circuit-bent-esque sounds.

In a general sense DU-KRPLS excels in glitches and micro-movements with millions of sweet spots. Circuit bent sounds are achieved with literally using wrong code.

CV inputs accept 0-5v.

TYPE and TRIG expect trigger inputs.

When a CV input jack is inserted, the knob on the left become an attenuator for the input signal.

DECAY control is very sensitive. Most of the time, keep it fully counterclockwise or fully clockwise.

Holding the button during powering up would quantize pitch to D Major Pentatonic scale.

More Information
HP 8
Depth 35 mm
+12V 35 mA
-12V 5 mA
Additional Resources All values printed on the PCB!
