Stereo bypass module to gate control the send of your signals to your favorite effect!
Molten bypass features a hard/soft bypass control, to hard cut the return of your effect or allow the long tails of your reverb to stay after you bypass the effect. Also a gate/latch control to use either triggers or gates for control and a gain control for the returned signal.
FEATURES
- Full stereo signal path.
- DC coupled.
- Hard or soft bypass selection.
- Gate or Latch possibility
- Manual or Gate control
- Gain control over the return.
| Brand | Molten Modular |
|---|---|
| HP | 4 |
| Depth | 42mm |
| +12V | 33mA |
| -12V | 26mA |
| Additional Resources | Build Guide |
